Fractal Design Define 7 XL Full Tower Desktop Case, 3x Dynamic X2 GP-14 Fans Included, Up to 480mm Radiator & 11x Max Fan Support, SSI-EEB Support, Moduvent Top Panel, Black
- New chassis design opens up to fully expose the case interior
- Anodized aluminum front panel with reversible dual-handed hinges
- Mount up to 18 HDD/SSDs plus five SSDs in the Storage Layout
Warranty: 1 Year — effortless warranty claims with UK-wide coverage. Learn more
Key specifications
- Color
- Black
- No of fans
- 3 Fans
- Form factor
- E-ATX Full Tower
- Side window
- Without Side Window
- Radiator support
- 480 mm
- External 5 25 inch drive bays
- 2
Details
- Shipping Weight
- 19.60 Kg
- Shipping Dimensions
- 35.50 cm x 65.00 cm x 70.00 cm
- 3.5"/2.5" Universal Drive Brackets
- 6 + 2 included, 18 positions total
- Dedicated 2.5" Drive Brackets
- 2 included, 5 positions total
- 5.25” Drive Mounts
- 2
- Expansion Slots
- 9 + 3
- Front Ports
- 1 x USB 3.2 Gen 2x2 Type-C (20 Gbps), 2 x USB 3.0, 2 x USB 2.0, Audio I/O, Power button, Reset button
- Total Fan Mounts
- 11 x 120 mm or 9 x 140 mm
- Front Fan
- 4 x 120 mm or 3 x 140 mm (2 x Dynamic X2 GP-14 included)
- Top Fan
- 4 x 120 mm or 3 x 140 mm
- Rear Fan
- 1 x 120/140 mm (1 x Dynamic X2 GP-14 included)
- Bottom Fan
- 2 x 120/140 mm
- Dust Filters
- Top, 2 x Front, Bottom + PSU
- Fixed Velcro Straps
- Yes
- Cable Routing Grommets
- Yes
- Captive Thumbscrews
- HDD brackets, SSD brackets, PSU bracket
- Left Side Panel
- Industrial sound-damped steel or Tempered Glass
- Right Side Panel
- Industrial sound-damped steel
- Motherboard Compatibility
- E-ATX / ATX / mATX / mITX / EE-ATX / SSI-CEB / SSI-EEB
- Power Supply Type
- ATX
- PSU Max Length
- 250 mm (both HDD cages installed)
- GPU Max Length
- Storage layout: 340 mm - Open layout: 530 mm (505 mm w/ front fan)
- CPU Cooler Max Height
- 185 mm
- Front Radiator
- Up to 480/420 mm
- Top Radiator
- Up to 480/420 mm
- Rear Radiator
- 120 mm
- Bottom Radiator
- Up to 240/280 mm
- Cable Routing Space
- 30 mm
- Vertical GPU Support
- 65 mm total clearance, standard 2-slot GPU (<38mm thickness) recommended for optimum cooling
- Case Dimensions (LxWxH)
- 604 x 240 x 566 mm
- Case Dimensions w/o Feet/Protrusions/Screws
- 590 x 240 x 548 mm
- Package Dimensions (LxWxH)
- 646 x 357 x 708 mm
- Net Weight
- Solid Version: 16.53 kg, TG Version: 16.64 kg
- Package Weight
- Solid Version: 18.73 kg, TG Version: 18.84 kg
- Volume
- 77.6 liters
