ASUS ROG Thor 1600W Titanium III Fully Modular Power Supply, 80 Plus Titanium Efficiency, Cybenetics Titanium Certification, Active PFC, ATX 3.1 Standard, GaN MOSFET Technology
- GaN MOSFET delivers up to 30% more power efficiency than standard MOSFETs and a more organized internal layout for cooler operation.
- "GPU-First" voltage sensing with patented intelligent voltage stabilizer enhances voltage delivery to your graphics card by up to 45% for smoother gaming and unwavering performance.
- Magnetic OLED display shows a real-time power draw and can be swapped to either side of the unit to accommodate fan-up or fan-down PSU installation.
Warranty: 1 Year — effortless warranty claims with UK-wide coverage. Learn more
Key specifications
- Power
- 1600 W
- Efficiency
- 80 Plus Titanium
Details
- Shipping Weight
- 6.20 Kg
- Shipping Dimensions
- 16.00 cm x 40.00 cm x 26.00 cm
- PFC Type
- Active PFC
- ATX Standard
- ATX 3.1
- Dimensions
- 200 x 150 x 86 mm
- MTBF
- >120000 hrs @ 25°C
- Protection Features
- OPP/OVP/UVP/SCP/OCP/OTP
- Hazardous Materials
- ROHS
- AC Input Range
- 100-240Vac
- DC Output Voltage
- +3.3V / +5V / +12V / -12V / +5Vsb
- Maximum Load
- 30A / 25A / 133.3A / 0.3A / 3A
- Combined Load
- 125W / 125W / 1600W / 3.6W / 15W
- Cable Connectors
- MB 24/20-pin x1, CPU 4+4-pin x2, PCI-E 6+2-pin x4, PCI-E 16-pin x2, SATA x10, PERIPHERAL x9
- Package Contents
- Power Cord x1, MB Cable x1, CPU Cable x2, PCI-E 16-pin x2, PCI-E 1-to-1 x4, SATA 1-to-4 x1, SATA 1-to-3 x2, Peripheral 1-to-3 x3, ARGB Cable x1, ROG Sticker x1, Cable Ties x18, Screws x1, User Manual x1
- Weight
- 2.80 kg (single PSU)
- AURA SYNC
- ARGB
- 0dB Technology
- Supported (fan shuts off under low load)
- 0dB Fan Button
- Yes (ON: Fan spins on load / OFF: Fan always spins)
4.38 reviews
Got something to share?
Rate this product — your experience helps other buyers.
Isla M. Used for: More than a year
Comment
Longest serving part in my machine now, and it has been through two graphics cards without complaint. The first was a 3090 that spiked hard enough to reset a lesser supply; this one never noticed. Two years in and the only thing that has changed is what is plugged into it. What I would change is the connector count. Titanium, 1600 watts, and only four PCIe leads in the box means a proper multi card setup needs daisy chaining, which defeats the point. The 12V-2x6 lead is short too, barely reaching a card mounted vertically. Everything electrical about it is superb, the accessory kit is where the corners got cut.
Theo K. Used for: Less than a month
Pros
Ate 5090 transients my old unit tripped on
Cons
The 24 pin lead is stiff enough to fight
Comment
Dropped into a fresh build with a 5090 and it took the transient spikes without so much as a flicker. My old 1000W GOLD unit used to trip on shader compilation. Cables are all individually sleeved and feel expensive, which at this money they should!
Ivy W. Used for: 3–6 months
Cons
Coil whine that changes pitch with frame rate
Comment
Coil whine. Not a faint tick in a silent room, a clear electrical squeal that changes pitch with frame rate and comes straight through a closed side panel. At 60fps capped it is a steady buzz, uncapped on a menu screen it turns into a whistle you can hear from the sofa across the room. Everything else is fine. Voltages hold steady, the fan is inaudible, the OLED readout is a nice toy. But nobody pays flagship money for a TITANIUM unit and then accepts a machine that sings at them all evening. The entire point of buying at this level is that you stop hearing the thing.
Isla R. Used for: 6–12 months
Pros
OLED wattage readout is genuinely useful
Cons
Enormous, and the cables are stiff as rope
Comment
The little OLED on the side is the reason I stopped bothering with a plug in meter. It reads what the machine is pulling in real time, and a 9800X3D with a 5090 sits around 620W in a heavy raster load, spiking to a bit over 900 in bursts. Titanium rating means the wall figure is barely higher than that. Fan has never audibly spun up, and that is most of a year of evening use now.
Isla C. Used for: 6–12 months
Cons
Comes with more cables than anyone needs
Comment
Faultless unit. Only grumble is the cable bag being bigger than some cases
Millie C. Used for: 1–3 months
Pros
Titanium efficiency without any fan noise
Cons
Takes up most of the PSU shroud
Comment
Silent, and the OLED tells me the 5080 rig idles at 90W
Harry M. Used for: 6–12 months
Pros
Huge headroom and the fan almost never turns
Comment
Went 1600W because the plan is two cards eventually and I would rather buy once. For now it feeds a single 4090 and a 14900K, which the readout says peaks at 780W under a stress test, so there is a lot in reserve. The fan does not turn below about half load, and I have only heard it once in nine months, on a hot afternoon with the room at 28 degrees. Dropping a star because the unit is 190mm long and my cable basement is now completely full.
Harry R. Used for: More than a year
Pros
Live wattage readout makes undervolting easy
Cons
Aura software is more faff than it is worth
Comment
Second Thor in this house and the reason is simple: the readout. Being able to glance at actual draw while tuning an undervolt saved me buying a meter. A 7900 XTX build settled at 480W after tuning, down from 560. Still on the original cables, still no whine, fan still silent.
