MSI MEG MAESTRO 700L PZ Mid-Tower Computer Case, Up to 360mm Radiator & 10x Fan Support, USB 3.2 Gen 2x2 Type-C, Enlarge Cable Routing Space, Black
- Can install up to 10 x system fans, providing ventilation and stable performance to the whole system.
- Compatible with ATX Back-connect motherboard.
- Support dual 360 mm radiator at the top and side simultaneously.
- Aluminum unibody frame construction made by 2.5 mm anodized aluminum.
- Synergize with a compatible MSI motherboard through bridging with a USB 3.2 Gen 2x2 Type-C (20Gbps) port for high speed data transmission.
- Vertical GPU bracket and PCIe 4.0 riser cable as accessories that allows you to mount your graphics card vertically.
Warranty: 1 Year — effortless warranty claims with UK-wide coverage. Learn more
Key specifications
- Color
- Black
- No of fans
- 10 Fans
- Form factor
- E-ATX Mid Tower
- Side window
- With Side Window
- Radiator support
- 360 mm
- External 5 25 inch drive bays
- None
Details
- Shipping Weight
- 17.00 Kg
- Shipping Dimensions
- 43.00 cm x 60.00 cm x 60.00 cm
- Product Name
- MEG MAESTRO 700L PZ
- Case Form Factor
- Mid-Tower
- Motherboard Support
- E-ATX (305 x 280 mm), ATX (Back-connect), M-ATX, ITX
- I/O Ports
- 1 x Power Button1 x Reset Button2 x USB 3.2 Gen 1 Type-A1 x USB 3.2 Gen 2x2 Type-C1 x Audio-Out / Mic-in
- Drive Mount Support
- 2 x 2.5"/3.5" combo bay
- Expansion Slots
- 7
- Max GPU Length
- 430 mm / 16.93 inches
- Max CPU Cooler Height
- 170 mm / 6.69 inches
- Power Supply Support
- ATX
- Max PSU Length
- 230 mm / 9.06 inches
- Fan Size Support
- Top: 3 x 120 mm / 3 x 140 mmRear: 1 x 120 mmSide: 3 x 120 mmBottom: 3 x 120 mm / 3 x 140 mm
- Radiator Size Support
- Top: 120 / 240 / 280 / 360 mm (80 mm thick)Rear: 120 mmSide: 120 / 240 / 360 mm (80 mm thick)Bottom: 120 / 240 / 280 / 360 mm
- Dimensions (DxWxH)
- 470 x 300 x 474 mm18.5 x 11.81 x 18.66 in
5.01 reviews
Got something to share?
Rate this product — your experience helps other buyers.
Ivy R. Used for: Less than a month
Pros
Back-connect cutouts that actually line up
Cons
Narrower inside than the E-ATX label suggests
Comment
Bought specifically for a Project Zero board, so the cutouts on the tray were the deciding feature. Everything lines up. The 24-pin, the EPS and the fan headers all come through the back of the tray and the panel still closes flat, which was my worry after reading about people shaving cable combs to make it fit. There is a good sixty millimetres of depth behind there, so even sleeved extensions are not a squeeze. The rest of the case is better than it needed to be. Ten fans preinstalled and wired to a hub, so the board only sees one header. Filters top and bottom, both magnetic. The glass panel is on a hinge with a catch, not thumbscrews. One warning: it is E-ATX in name but the width is at the modest end, so a very tall air cooler and a back-connect board together will have you checking the clearance chart before you commit.
