ASUS ROG CROSSHAIR X870E APEX AM5 ATX Motherboard, AMD X870E Chipset, 2x DIMM DDR5 Slots, Up to 128GB Max Memory, 2x PCIe 5.0 x16 Slots, 5x M.2 Slots, Wi-Fi7 & BT5.4
- Teamed Power Solution
- Overclocking Effortless performance boost
- AI Networking II
- AI Cooling II One-click fan tuning
- DDR5 Max. 128 GB, AEMP
- Extensive Gen 5 x3 onboard M.2 slots, and x2 PCIe 5.0 x16 slots
Warranty: 1 Year — effortless warranty claims with UK-wide coverage. Learn more
Key specifications
- Socket
- AM5
- Chipset
- AMD X870E
- Form factor
- ATX
- Memory type
- DDR5
- Memory slots
- 2
Details
- Shipping Weight
- 3.90 Kg
- Shipping Dimensions
- 11.50 cm x 37.00 cm x 32.00 cm
- M.2 Slots
- 5
- Maximum Memory
- 128 GB
- PCI Express x16
- 2
- CPU Support
- AMD Socket AM5 for Ryzen™ 9000/8000/7000
- Memory
- 2x DIMM, DDR5, max 128GB, Dual-channel, ECC/Non-ECC, EXPO & AEMP support
- Memory Speed
- Up to 8200+MT/s (9000), 9600+MT/s (8000), 8000+MT/s (7000)
- Graphics
- 2x USB4 (40Gbps, Type-C, DP 1.4a), up to 4K@60Hz
- Expansion Slots
- Varies by CPU. PCIe 5.0/4.0 x16 slots, Q-Release Slim
- Storage
- 5x M.2 (varies PCIe version by CPU), 4x SATA 6Gb/s
- RAID
- 0/1/5/10 (9000), 0/1 (8000), 0/1/10 (7000)
- Ethernet
- Realtek 5Gb Ethernet + ASUS LANGuard
- Wi-Fi / BT
- Wi-Fi 7 (802.11be), BT 5.4
- Rear USB Ports
- 2x USB4, 6x USB 10Gbps (Type-A/C), 2x USB 5Gbps
- Front USB Ports
- 1x USB 20Gbps Type-C (60W PD), 1x USB 20Gbps C, 4x USB 5Gbps, 4x USB 2.0
- Audio
- ROG SupremeFX ALC4080, 7.1ch, SPDIF, 120 dB SNR, Savitech AMP
- Back I/O
- USBs (as above), Wi-Fi, 5GbE, PS/2, audio jacks, SPDIF, BIOS FlashBack, Clear CMOS
- Internal I/O
- Multiple fan, pump, USB, audio, thermal, debug, and OC headers/switches
- Special Features
- LN2, Safe Boot, Start, Slow Mode, BIOS FlashBack™, Q-Design, Aura Sync, AI Cooling II
- USB Type-C Fast Charging
- 60W QC 4+ (requires 8-pin PCIe), supports PD3.0 & PPS
- Software
- ROG CPU-Z, Armoury Crate, Dolby Atmos, AI Advisor, etc.
- BIOS
- Dual 256Mb UEFI AMI BIOS, CrashFree, EZ Flash, MyHotkey
- Accessories
- ROG DIMM.2 Heatsink, Wi-Fi Antenna, M.2 kits, Q-connector, Bottle Opener, USB drive
- OS Support
- Windows 11 (22H2 & later)
