NETGEAR GSM4230UP 24-Port Gigabit PoE++ Managed Network Switch with SFP, 60 Gb/s Switching, 1440W Power Budget
NETGEAR
- AV Line M425
- M4250-26G4F-PoE++
- Designed with input from industry professionals, the AV Line M4250 GSM4230UP 24-Port Gigabit PoE++ Compliant Managed Network Switch from Netgear is engineered for 1G AV over IP. Enjoy 24 rear-facing 60W PoE++ compliant RJ45 ports with a 1440W power budget and four Gigabit SFP uplink slots that ensure a clean integration in AV racks and pre-configuration for out-of-the-box functionality.
- 24 x Gigabit Ethernet PoE++ Ports
- 4 x Gigabit SFP Ports
Warranty: 1 Year — effortless warranty claims with UK-wide coverage. Learn more
Key specifications
- Port speed
- Gigabit
Details
- Shipping Weight
- 4.30 Kg
- Shipping Dimensions
- 25.00 cm x 44.00 cm x 43.00 cm
- - 24 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) PoE (Type 4)
- - 4 x 10/100/1000 Mb/s Gigabit SFP+
- - 2 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) (Console)
- - 2 x USB-C (Console)
- - Layer 2 Support
- - Layer 3 Support
- - DHCP Server
- - IGMP Snooping
- - IPv4
- - IPv6
- - Link Aggregation
- - Port Mirroring
- - SNMPv1
- - SNMPv2c
- Jumbo Frames Support
- 12000 Bytes
- MAC Address Table Size
- 16 K
- VLAN Groups
- 4093
- - DHCP Snooping
- - DoS Attack Prevention
- - RADIUS Authentication
- - Storm Control
- Access Control List
- 1024
- SNMP Support
- 1, 2, 3
- Forwarding Rate
- 44.64 Mpps
- Switching Bandwidth
- 60 Gb/s
- Packet Buffer
- 16 MB
- CPU
- Quad-Core: Up to 1.8 GHz Cortex A (57)
- Memory
- 2 GB
- PoE Power Budget
- 1440 W
- PoE per Port
- 90 W
- Power Supply Type
- Internal
- Operating Temperature
- 32 to 77°F / 0 to 45°C
- Operating Humidity
- 90%
- Storage Temperature
- -4 to 158°F / -20 to 70°C
- Storage Humidity
- 95%
- Operating Altitude
- 10000' / 3048 m
- Storage Altitude
- 10000' / 3048 m
- Noise Level
- 34.0 dB (Active)
- Cooling System
- Fan/Passive Combo
- Indicator Lights
- Link/Activity/Speed, PoE
- Rack Form Factor
- 1 RU
- Dimensions
- 17.3 x 10.1 x 1.7" / 440 x 257 x 43.2 mm
- Weight
- 9.5 lb / 4.3 kg
4.52 reviews
Got something to share?
Rate this product — your experience helps other buyers.
Freya K. Used for: Less than a month
Pros
Per-port power draw shown in the web interface
Cons
Fans are audible the moment it powers up
Comment
Racked it, gave it an address, and had the VLANs done before lunch. The web interface is plain and quick, no plugin needed, and the port view shows you which sockets are drawing power and how much!
Sophie R. Used for: 1–3 months
Pros
PoE budget with real headroom left over
Comment
Twenty-four ports with a PoE budget big enough to run every camera on the site and still have headroom for the access points, which was the whole reason for the upgrade. It is a rack-depth metal box with fans that you will hear in a quiet room, so it wants a cupboard. Everything else about it has been straightforward.
