Ubiquiti Pro Max 48 PoE Network Switch, 1.3" Touchscreen, 32x GbE RJ45 ports, 224 Gbps Switching Capacity, 720W Total Available PoE, SGCC Steel Material, Black

Details

Shipping Weight

7.25 Kg

Shipping Dimensions

12.00 cm x 54.00 cm x 52.00 cm

Dimensions

442.4 x 400 x 44 mm (17.4 x 15.7 x 1.7")

Weight

Without mounting brackets: 6.2 kg (13.7 lb)With mounting brackets: 6.3 kg (13.9 lb)

Enclosure Material

SGCC steel

Management Interface

Ethernet In-Band

Networking Interface

(32) GbE RJ45 ports(16) 1/2.5 GbE RJ45 ports(4) 10G SFP+ ports

PoE Interface

(32) PoE/PoE+ (Pins 1, 2+; 3, 6-)(16) 60W PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-)

Total Non-Blocking Throughput

112 Gbps

Switching Capacity

224 Gbps

Power Method

(1) Universal input, 100—240V AC, 50/60 Hz(1) USP-RPS DC input

Power Supply

AC/DC, internal, 820W

Supported Voltage Range

100—240V AC

Max Power Consumption

100W (Excluding PoE output)

Total Available PoE

720 W

Max PoE Wattage per Port by PSE

PoE: 15.4WPoE+: 30WPoE++: 60W

Voltage Range PoE Mode

PoE: 44—57VPoE+: 50—57V

LCM Display

(1) 1.3" touchscreen

Button

Factory reset

Ambient Operating Temperature

-5 to 40° C (23 to 104° F)

Ambient Operating Humidity

10 to 90% noncondensing

Certifications

CE, FCC, IC

Layer 2 Features

IGMP snoopingSTP / RSTP with priorities and port-level disablePort isolationStorm controlVoice VLANPort mirroringLACP port aggregationMulticast / broadcast rate limitingMAC address blockingFlow control802.1X controlJumbo framesProprietary loop protectionDHCP snooping / guardingEgress rate limitLLDP-MEDPort restricted by MACDevice isolation with ACLs

Layer 3 Features

DHCP for locally-managed networksDHCP relayInter-VLAN routing between networks on same switchStatic routing between local networksNetwork isolation with ACLs

System

Status

RPS

Status

UniFi Network

Version 8.0.24 and later
