Ubiquiti Networks UniFi Pro PoE 48-Port Gigabit Managed PoE Network Switch with SFP+, 176 Gb/s Switching, 130.94 Mpps Fwd Capacity, 1.3" Display, 4 x 10 Gb/s SFP+ Ports
UBIQUITI
- 48 x Gigabit Ethernet Ports
- 40 x PoE+ Ports | 8 x PoE++ Ports
- 4 x 10 Gb/s SFP+ Ports
- 176 Gb/s Switching Capacity
- 130.94 Mpps Forwarding Capacity
- Rack-Mountable Design
- 1.3" Touchscreen Display
Warranty: 1 Year — effortless warranty claims with UK-wide coverage. Learn more
Key specifications
- Port speed
- Gigabit
Details
- Shipping Weight
- 6.80 Kg
- Shipping Dimensions
- 12.00 cm x 52.00 cm x 51.00 cm
- Dimensions
- 442 x 400 x 44 mm (17.4 x 15.7 x 1.7")
- Weight
- Without mounting brackets: 6.2 kg (13.8 lb)With mounting brackets: 6.3 kg (14 lb)
- Enclosure material
- SGCC steel
- Management interface
- Ethernet In-Band
- Networking interface
- (48) GbE RJ45 ports(4) 1/10G SFP+ ports
- PoE interface
- (40) PoE/PoE+ (Pins 1, 2+; 3, 6-)(8) 60W PoE++; PoE/PoE+ (Pins 1, 2+; 3, 6-) / PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-)
- Total non-blocking throughput
- 88 Gbps
- Switching capacity
- 176 Gbps
- Forwarding rate
- 130.944 Mpps
- Power method
- (1) Universal input, 100—240V AC, 50/60 Hz(1) USP-RPS DC input, 52V DC, 11.54A; 11.5V DC, 5.22A
- Power supply
- AC/DC, internal, 660W
- Supported voltage range
- 100—240V AC
- Max. power consumption
- 60W (Excluding PoE output)
- Total available PoE
- 600 W
- Max. PoE wattage per port by PSE
- PoE+: 32WPoE++: 64W
- Voltage range PoE mode
- PoE: 44—57VPoE+: 50—57V
- ESD/EMP protection
- Air: ± 16kV, contact: ± 12kV
- LCM display
- (1) 1.3" touchscreen
- Button
- Factory reset
- Shock and vibration
- ETSI300-019-1.4 Standard
- Operating temperature
- -5 to 40° C (23 to 104° F)
- Operating humidity
- 10 to 90% noncondensing
- Certifications
- CE, FCC, IC
- System
- Status
- Ethernet
- PoESpeed/link/activity
- SFP+
- Link/activity
- RPS
- Status
- UniFi Network
- Version 5.10.5 and later
