EIKON EKSBIPRO 192khz USB Audio Interface, XLR Female, Balanced Type, 2x XLR/TRS Inputs with HI-Z Switch, High-Definition MIC Preamps with Extended Dynamic Range, USB Bus-Powered
EIKON
- Two XLR/TRS inputs with HI-Z switch for recording vocals and instrument together or stereo sources
- High-definition MIC preamps with extended dynamic range and 48V phantom power
- 2-in + 2-out high-resolution 24-bit/192KHz USB2.0 interface for a flawless audio quality
- Zero-latency DIRECT MONITORING with STEREO/MONO selector and mixing control between input signals and DAW playback
- Analog outputs for connecting studio monitors
Warranty: 1 Year — effortless warranty claims with UK-wide coverage. Learn more
Key specifications
- Connection
- USB
Details
- Type
- XLR female, balanced
- Frequency Response
- 10 Hz to 22 kHz (±3.0 dB)
- Input Impedance
- 1.32 kΩ (Balanced)
- THD+N
- < 0.005% (1 kHz @ +4 dBu Output, Unity Gain)
- S/N Ratio
- > 99 dB (Unity Gain, Ref. = +4 dBu, 20 Hz–22 kHz)
- CMRR
- > 65 dB (1 kHz, 40 dB Gain)
- Gain Control Range
- 0 dB to 45 dB (±1 dB)
- Max Input Level
- -2 dBu (Unity Gain, 1 kHz @ 0.1% THD+N)
- Phantom Power
- +48 VDC (±2 VDC)
- Output Impedance
- 600 Ω
- Maximum Output
- 50 mW/ch. @ 32 Ω Load
- ADC Dynamic Range
- 108 dB (A-weighted, 48 kHz Sample Rate)
- DAC Dynamic Range
- 109 dB (A-weighted, 48 kHz Sample Rate)
- Bit Depth
- 16 / 24 / 32
- Reference Level 0 dBFS
- +10 dBu
- Sample Frequencies
- 44.1, 48, 88.2, 96, 176.4, 192 kHz
- Power
- USB bus-powered
- Height
- 52 mm (2.05")
- Depth
- 106 mm (4.17")
- Width
- 160 mm (6.30")
- Weight
- 0.55 kg (1.21 lbs)
