SAMSUNG 9100 PRO 2TB Capacity, PCIe 5.0 NVMe M.2 Internal SSD, V-NAND TLC Type, Up to 14,700 MB/s Sequential Read & Up to 13,400 MB/s Sequential Write, TRIM & SMART Support
- PCIe 5.0 Performance
- Boost AI Applications
- Innovative Power & Thermal Control
- Always Up-to-Date via Magician Software
Warranty: 1 Year — effortless warranty claims with UK-wide coverage. Learn more
Key specifications
- Capacity
- 2 TB
- Form factor
- M.2
- Storage type
- Internal SSD
Details
- Shipping Weight
- 0.10 Kg
- Shipping Dimensions
- 2.00 cm x 10.00 cm x 14.50 cm
- Article Name
- 9100 PRO PCIe® 5.0 NVMe™ M.2 SSD - 2TB
- Storage Type
- Samsung V-NAND TLC
- Controller
- Samsung in-house controller
- Cache Memory
- Samsung 2GB Low Power DDR4X SDRAM
- Connectivity
- PCIe® 5.0 x4, NVMe™ 2.0
- Device Dimensions
- 80.15 x 22.15 x 2.38mm (max.)
- Weight
- 9.0 g
- Power Consumption (Operation)
- Read: 8.1W / Write: 7.9W
- Power Consumption (Idle)
- 4.8 mW
- Power Consumption (Device Sleep)
- 4 mW
- Operating Voltage
- 3.3V ± 5%
- Reliability (MTBF)
- 1.5 million hours
- Operating Temperature
- 0°C to 70°C
- Shock Resistance
- 1500 G duration & 0.5 m/sec. (half sine)
- Sequential Read Speed
- Up to 14700 MB/s
- Sequential Write Speed
- Up to 13400 MB/s
- Random Read
- Up to 1850,000 IOPS
- Random Write
- Up to 2600,000 IOPS
- TRIM Support
- Yes
- SMART Support
- Yes
- Garbage Collection
- Auto Garbage Collection Algorithm
- Encryption
- AES 256-bit (Class 0), TCG/Opal IEEE1667
- WWN Support
- No
- Device Sleep Mode
- Yes
- Software
- Magician software for SSD management
- Application
- Client PCs, Game Consoles
- Installation Accessories
- No
4.99 reviews
Got something to share?
Rate this product — your experience helps other buyers.
Theo H. Used for: 6–12 months
Pros
The console has never once complained
Cons
A PS5 cannot use half of what it can do
Comment
Went into a PS5 with an aftermarket heatsink and the console has been perfectly happy with it for eight months. Loading is quick enough that the difference against the internal drive is not something I can honestly claim to notice.
Maya P. Used for: 1–3 months
Pros
Never throttles under a long write
Cons
The active heatsink fan spoils a quiet build
Comment
Excellent drive, and the only reason it is not five is the cooling situation. On this board the Gen5 slot heatsink has an active fan, and under a long write that fan is clearly audible over everything else in the case. The drive itself never throttles, which is presumably the fan doing its job, but if you have built a quiet machine deliberately then be aware that a Gen5 drive changes that. Performance is not in question at all.
Jack R. Used for: More than a year
Cons
The price still stings
Comment
No faults at all, and it has been in constant use since the machine was built. The only thing I would change is the price, which still stings.
Harry H. Used for: More than a year
Pros
Never once complained
Cons
Runs hot without a proper heatsink
Comment
Fastest drive in the house and it has never once complained. Superb!
Jack W. Used for: More than a year
Pros
A hundred thousand small files copy in no time
Cons
Far too hot for a laptop
Comment
Two of these in a workstation, one for the operating system and one for project files, and the pair have handled everything a year of client work has thrown at them. The useful measure for me is not the peak number, it is that a folder of a hundred thousand small files copies in a fraction of the time the old drives took. Wear indicators are both at three per cent. Only complaint is that the drive is unusable in a laptop, far too hot.
Grace M. Used for: More than a year
Pros
Holds the same numbers it did on day one
Comment
Two terabytes of Gen5 in the primary slot, and a year on it still holds the same benchmark numbers it did the day it went in!
Grace M. Used for: 1–3 months
Comment
Replaced a pair of Gen3 drives with this single one and reclaimed a slot in the process, which was half the reason for buying it. Copying everything across from both old drives, about 1.4 terabytes in total, took under six minutes and the drive did not drop below 4GB/s at any point. That is the bit that impressed me, because every drive is fast for the first thirty seconds. It does want a heatsink. Mine is under the motherboard's own and idles at 44, which is warm but nothing to worry about, and it has not throttled once.
Isla K. Used for: 6–12 months
Pros
Virtual machines boot almost instantly
Cons
Needs a board that can actually feed it
Comment
Bought to hold a growing library of virtual machines and it has made spinning one up almost instant. Boot a VM, it is at the login screen before the window has finished drawing. Nothing else I have used comes close for that particular job!
Millie M. Used for: 3–6 months
Pros
Speed nothing else in the build can match
Cons
Expensive
Comment
Ridiculous speed. The rest of the machine cannot keep up
