Focusrite Scarlett 18i20 USB Audio Interface, 18 In 20 Out Recording Interface, 24 Bit 192kHz, 8 Mic Preamps, ADAT S PDIF MIDI I O, USB C Studio Interface
Focusrite
- Eight ultra-low-noise mic/line preamps
- Two front-panel mic/line and instrument preamps
- Two Air preamp modes for classic console sound
- Clip Safe and Auto Gain modes
- 10 line outputs inc. alt speaker switching
- Up to 16 channels of ADAT I/O
- S/PDIF, MIDI, and Word Clock
- Includes Hitmaker Expansion and DAW software bundle
Warranty: 1 Year — effortless warranty claims with UK-wide coverage. Learn more
Key specifications
- Connection
- USB
Details
- Shipping Weight
- 4.30 Kg
- Shipping Dimensions
- 10.00 cm x 50.00 cm x 35.00 cm
- Microphone Preamps
- 8
- Phantom Power
- Yes (Independent)
- Instrument Inputs
- 2
- Line Inputs
- 8
- Air Mode
- Yes
- Auto Gain
- Yes
- Clip Safe
- Yes
- Line Outputs
- 10
- Headphone Outputs
- 2
- ADAT Inputs
- 2 (up to 8 channels at 96kHz)
- ADAT Outputs
- 2 (up to 8 channels at 96kHz)
- SPDIF Inputs
- 1
- SPDIF Outputs
- 1
- MIDI Inputs
- 1
- MIDI Outputs
- 1
- Talkback
- Yes
- Loopback
- Yes
- Connectivity
- USB Type-C
- Protocol
- USB 2.0
- Form Factor
- Desktop / Rack Mountable (1U)
- Simultaneous I/O
- 20 x 24 (including Loopback)
- A/D Resolution
- 24-bit/192 kHz
- Bus Powered
- No
- Dimensions (H x W x D)
- 46.55 mm x 259.73 mm x 442 mm
- Weight
- 3.304 kg
- Supported Sample Rates
- 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
- - Frequency Response
- 20-20kHz ± 0.06dB
- - Dynamic Range
- 116dB (A-Weighted)
- - THD+N
- -100dB @ 8dB gain
- - Noise EIN
- -127dBu (A-Weighted)
- - Maximum Input Level
- 16 dBu
- - Gain Range
- 69 dB
- - Impedance
- 3kΩ
- - Maximum Output Level
- 16 dBu
- - Maximum Output Power
- 57mW into 33Ω, 27mW into 300Ω
- Power
- External 30W
